8.1.0-RC3 Release Notes

We strongly recommend that you take advantage of the release candidates as they come out. Waiting for a GA release is only going to set you up for unpleasant surprises. A GA is a tag and nothing more. Note that CAS releases are strictly time-based releases; they are not scheduled or based on specific benchmarks, statistics or completion of features. To gain confidence in a particular release, it is strongly recommended that you start early by experimenting with release candidates and/or follow-up snapshots.

Apereo Membership

If you benefit from Apereo CAS as free and open-source software, we invite you to join the Apereo Foundation and financially support the project at a capacity that best suits your deployment. Note that all development activity is performed almost exclusively on a voluntary basis with no expectations, commitments or strings attached. Having the financial means to better sustain engineering activities will allow the developer community to allocate dedicated and committed time for long-term support, maintenance and release planning, especially when it comes to addressing critical and security issues in a timely manner.

Get Involved

Resources

System Requirements

The JDK baseline requirement for this CAS release is and MUST be JDK 25. All compatible distributions such as Amazon Corretto, Zulu, Eclipse Temurin, etc should work and are implicitly supported.

New & Noteworthy

The following items are new improvements and enhancements presented in this release.

OpenRewrite Recipes

CAS continues to produce and publish OpenRewrite recipes that allow the project to upgrade installations in place from one version to the next. See this guide to learn more.

Graal VM Native Images

A CAS server installation and deployment process can be tuned to build and run as a Graal VM native image. We continue to polish native runtime hints. The collection of end-to-end browser tests based on Puppeteer have selectively switched to build and verify Graal VM native images and we plan to extend the coverage to all such scenarios in the coming releases.

Testing Strategy

The collection of end-to-end browser tests based on Puppeteer continue to grow to cover more use cases and scenarios. At the moment, total number of jobs stands at approximately 556 distinct scenarios. The overall test coverage of the CAS codebase is approximately 94%.

JSpecify & NullAway

CAS codebase is now annotated with JSpecify annotations to indicate nullness contracts on method parameters, return types and fields. We will gradually extend the coverage of such annotations across the entire codebase in future releases and will integrate the Gradle build tool with tools such as NullAway to prevent nullness contract violations during compile time.

Spring Boot 4.2

CAS is now built on top of Spring Boot 4.2.x. This is an in-progress ongoing minor platform upgrade that affects almost all aspects of the codebase including many of the third-party core libraries used by CAS as well as some CAS functionality.

Please refer to the Spring Boot Wiki for more information on the changes and updates in this release.

Documentation

The CAS documentation site has received a visual and functional overhaul. Notable changes include:

  • A refreshed theme with light and dark modes, a serif typeface for headings, a monospaced sidebar, and quiet icons for recurring sections such as configuration, actuator endpoints and troubleshooting.
  • Configuration settings are presented as a searchable, filterable reference list. Each setting can be expanded to show its description, type, default value and deprecation status, and copied as .properties, YAML or environment variables. The chosen format is remembered across pages.
  • Actuator endpoints are grouped by endpoint, with each operation listing its parameters, response and a working curl example inline. Instructions to enable, expose and secure the endpoint along with related settings and troubleshooting notes are shown once per endpoint rather than once per operation, which makes pages considerably lighter.
  • The configuration properties search is rewritten. It matches setting names regardless of how they are written (property names, environment variables or pasted assignments), supports exact name matches, searches names or descriptions, filters CAS or third-party and deprecated settings, and keeps the search in the page address so results can be shared.
  • Pressing Shift twice on any documentation page opens a quick search for configuration settings.
  • Feature toggles are grouped by area and can be searched or filtered to those that are off by default. Each feature can be expanded to show its modules, their default state, the auto-configuration classes they control and a link to the relevant documentation, and every toggle can be copied as .properties, YAML or environment variables.
  • The documentation build and validation time is significantly reduced and changes are now published up to 75% faster. External links are checked on a weekly schedule rather than on every change, and broken external links no longer block publishing.

Heimdall AuthZEN

Heimdall AuthZEN support is reworked to follow the AuthZEN Authorization API 1.0 specification:

  • The AuthZEN resource.id now identifies the resource instance rather than a policy namespace. AuthZEN requests are matched against resources in all namespaces by their new resourceType, actions and optional resourceIdPattern fields, and all matching resources must grant access. Existing AuthZEN resources must define these fields, or AuthZEN requests are denied; requests to /heimdall/authorize are unaffected.
  • Evaluated denials return 200 with "decision": false, malformed requests 400, and failed caller authentication 401. The X-Request-ID header is echoed.
  • Tokens must be issued to a registered OAuth or OpenID Connect application whose access strategy allows access, and a new Heimdall access strategy can prevent an application from calling Heimdall. DPoP-bound and certificate-bound tokens now require their proof. On the AuthZEN endpoint, Basic credentials are the client_id:client_secret of a registered application rather than CAS user credentials.
  • JWT bearer assertions must carry jti and iat claims, are accepted once, and may not live longer than cas.heimdall.jwt-assertion-max-lifetime (five minutes by default).
  • Failed caller authentication on /heimdall/authorize now returns 401 instead of 403. Failed caller authentication on both Heimdall endpoints is subject to authentication throttling.
  • A resource with no policies now denies access instead of granting it, and the REST policy no longer sends the resource’s policies to its endpoint.
  • JDBC policies use a shared connection pool, registered as an application context bean and optionally named via dataSourceName, instead of opening a new database connection for every decision. Queries time out after queryTimeout (five seconds by default). Policies are evaluated in order rather than on the shared thread pool.
  • AuthZEN subjects are resolved from CAS attribute repositories only for the user subject type. Required and rejected attribute policies accept qualified names such as subject.properties.department, resource.properties.owner, action.properties.method and context.channel. HTTP request headers are no longer added to the AuthZEN request context; on /heimdall/authorize they no longer override body entries or include protocol headers.
  • A resource that does not set enforceAllPolicies is now granted when any one of its policies grants access, as documented; previously every policy had to grant. Set enforceAllPolicies to true on resources that rely on the old behavior. In that mode, a policy that fails with an error no longer prevents a later policy from granting access.
  • Heimdall supports the AuthZEN access evaluations API at /heimdall/authzen/evaluations, with the execute_all, deny_on_first_deny and permit_on_first_permit semantics.
  • Heimdall publishes AuthZEN policy decision point metadata at /heimdall/.well-known/authzen-configuration; the well-known location defined by the specification needs a rewrite rule.
  • Denied AuthZEN decisions carry a decision context with a reason code.
  • JDBC and OpenFGA policies receive the AuthZEN subject, resource and action. Palantir can edit the AuthZEN fields of a resource and configure the Heimdall access strategy.

Certificate-Bound Access Tokens

The certificate thumbprint that CAS records for mutual TLS client authentication and emits as the cnf x5t#S256 claim of access tokens and introspection responses is now computed as specified by RFC 8705: the base64url-encoded SHA-256 hash of the DER-encoded certificate. Previously, it was computed from the certificate’s public key and was not encoded as specified. Certificate-bound tokens issued before the upgrade carry the old value and are no longer accepted by resource servers that verify the binding.

Authentication Throttling

Authentication throttling now records a failed attempt only when the response status is 401, once per request. Previously, any response other than 200, 201 or 302, such as a malformed request (400), an authorization denial (403), a missing resource (404) or a server error (500), was counted as a failed login, and failures were recorded twice. Failed SAML2 ECP authentication attempts, which answer with a SOAP fault, are now counted as well.

Other Stuff

  • A large number of dependencies and libraries have been updated to their latest versions.
  • Almost all CAS unit tests are internally reworked to allow maximum parallelization and speed up the overall test execution time.
  • Delegated authentication no longer fails intermittently when concurrent requests reach an identity provider that is still being initialized, typically right after startup. Such requests now wait for the initialization in progress instead of failing, which also affects SAML2 identity providers when building SAML2 responses, metadata and logout requests.
